12kw YIY hybrid split phase solar inverter 120/240 stackable MPPT
$1,999.00 Original price was: $1,999.00.$1,400.00Current price is: $1,400.00.
12kw hybrid solar inveerter YIY stackable to 6 units
split phase 120/240
MPPT dual controller built in
YIY model: SVP48120LV-P
120/240 L+N+L
bypass 2 pole 60a
pure sine
splitphase
Stackable to 6 units
designed for off grid hybrid no sale back but has AC input to charge from grid.
battery rated voltage is 51.2v min start 44v
range is 40.0v – 58.6v
power saving consumption only 25w
max charge total is 160A
short circuit protection fused
500vdc MPPT voc
90-450v mppt working range
max pv is 6000W + 6000W dual controller
UL1741 and CSA C22.2
FCC part 15 class B
Variable fan cooling
USB, RS485 WIFI and Can Bus connections
it’s 620mm x 450mm 132mm and only weighs 53lbs
50 or 60hz operation
over 95% efficiency
data sheet and manual in data sheets below
best paired with Yilink 15k and 10k batteries on our site
