Yilink Solar Battery
Rackmount 5kwh LifePO4 solar battery
Lithium Solar battery
Series iPower Rack
Battery Type LiFePO4
Model YL-S48100
Nominal Voltage[V] 48
Nominal Capacity[Ah] 100
Nominal Energy[kWh] 4.8
Max. output Power[kW] 4.8
Net Weight[Kg] 45
Dimension [mm]W*D*H 442*460*178
Working Voltage[V] 40~54
Operating Temperature Charging[°C] 0~55
Operating Temperature Discharging[°C] -20~60
Max. Charge Current[A] 100
Max. Discharge Current[A] 100
Recommend Charge Current[A] 20
Charge Mode CC-CV
Communication CAN/RS485/RS232/Dry Contact
IP Level IP30
Temperature & Period Storage[°C]
Less than 6 Month@-10°C~35°C
Less than 3 Month@-10°C~45°C
Less than 1 Month@-20°C~45°C
Warranty 10 years
Tried and true 1 of 3 brands that are in the North America that are True Grade A batteries 99% of all other brands are grade B
and we can prove it our FCC is far higher than what you are paying for you will get alot more AH than just 100ah so as the unit breaks down over time
we garrantee it to have 100AH at 10 years of use.
Gross weight of the boxed unit is 100lbs
Thousands Installed and operational
Great Support for product.
This battery works very well with over 100 different solar inverters on the market today.
You can use this with outback, xantrex, schneider, mpp, voltronics, solark, sma, fronius, and more.
We have helpful charts for outback, xantrex, schneider, mpp, trace, sma, fronius as these units do not have RS485 but can still work very well with the batteries.
Battery cells are “Cherry Picked” to provide a higher yield and longer life than 90% of other brands on the market today.
These batteries are about 1/4 of the price of the Tesla Powerwall and are built to last just as long with stringent testing and great support for our products.
With less than a 0.02% failure rate these are the highest performing battery in North America. Over 8000 rackmount batteries sold to date.
Very simple BMS internal board can be swapped out in the event of a BMS failure.
Cells are all welded in place no soldering that can result in poor connections over time.
Can be parallel connected to 16 batteries with lan cables. (provided in the box)
If you have any questions or concerns please reach our to us with our contact form or email us at sales@buycheapsolar.com and we will happily answer your questions about these.
We have been selling Yilink for many years and have a very easy and precise support for all our products.
Yilink is a top tier company you can review their information as well here: https://www.yilink-energy.com/
We recommend our Voltronics Inverter with these as it comes default setup to work.
You can view it here: https://buycheapsolar.com/shop/solar-inverters/6kw-48v-on-grid-hybrid-infinisolar-inverter-new-ul-and-cec-listed/
